25 ALS / ADS - 25,000 FT-LBS

High-Efficiency Hydraulic Motors: Equipped with Eaton/Digga bell geroler hydraulic motors featuring integrated pressure relief valves, you will get higher RPM and greater torque than competing drives.

Energy Control Valve: Say goodbye to rapid oil decompression caused by pile kick-back. Our drives come standard with an Energy Control Valve (ECV / Swoosh Valve) ensuring smooth operation and extended equipment lifespan.

Robust Construction: Engineered with a sturdy hood and ears for maximum strength, our drives are built to withstand the toughest working conditions, providing you with unmatched durability and peace of mind.

Warranty Assurance: Backed by a 3-year gearbox and 2-year motor warranty, our drives offer not only superior performance but also long-term reliability.

Rev-Pile Inc. 25,000 FT-LBS Screw Pile Drive Specifications

25ALS - 3000 PSI

Nominal Torque - 26,375 FT-LBS

Max Pressure - 3000 PSI @ 33 GPM

Max Flow - 61GPM @ 1800 PSI

Pressure Relief Valve - Included

Energy Control Valve - Included

Output Shaft - 100mm Square

Weight - 637 LBS (with hood)

Overall Length - 45.3” (with hood)

Overall Diameter - 14”

25ADS - 3500 PSI

Nominal Torque - 24,514 FT-LBS

Max Pressure - 3500 PSI @ 33 GPM

Max Flow - 61GPM @ 1800 PSI

Pressure Relief Valve - Included

Energy Control Valve - Included

Output Shaft - 100mm Square

Weight - 637 LBS (with hood)

Overall Length - 45.3” (with hood)

Overall Diameter - 14”

• HALO Alignment System (Magnetic Battery Pack or Power Cables Sold Separately)
• Excavator Mounts
• Skid Steer Mounts
• Linkages
• Adaptors
• Torque Monitor Systems
• Pressure Differential Gauges

Rev-Pile Inc. 25,000 FT-LBS Screw Pile Drive - Sales Sheet

Coming Soon
