SKU: PDI-30-ADS

30 ADS - 30,000 FT-LBS

Vendor Rev-Pile™
Regular price $17,557.00 CAD
Sale price $17,557.00 CAD Regular price
Sale Sold out
Unit price
/per
This is a pre order item. We will ship it when it comes in stock.

Digga 30ADS - 30,000 FT-LBS

Options Available

  1. Standard Hood with Top Ears & Pin or Gimbal Mount
  2. No Alignment System or HALO Alignment System Factory Installed

High-Efficiency Hydraulic Motors: Equipped with Eaton/Digga bell geroler hydraulic motors featuring integrated pressure relief valves, you will get higher RPM and greater torque than competing drives.

Energy Control Valve: Say goodbye to rapid oil decompression caused by pile kick-back. Our drives come standard with an Energy Control Valve (ECV / Swoosh Valve) ensuring smooth operation and extended equipment lifespan.

Robust Construction: Engineered with a sturdy hood and ears for maximum strength, our drives are built to withstand the toughest working conditions, providing you with unmatched durability and peace of mind.

Warranty Assurance: Backed by a 3-year gearbox and 2-year motor warranty, our drives offer not only superior performance but also long-term reliability.

Rev-Pile Inc. 30,000 FT-LBS Screw Pile Drive Specifications

30ADS - 3500 PSI

Nominal Torque - 30,771 FT-LBS

Max Pressure - 3500 PSI @ 33 GPM

Max Flow - 61GPM @ 1800 PSI

Pressure Relief Valve - Included

Energy Control Valve - Included

Output Shaft - 100mm Square

Weight - 637 LBS (with hood)

Overall Length - 45.3” (with hood)

Overall Diameter - 14”

  • HALO Alignment System (Magnetic Battery Pack or Power Cables Sold Separately)
  • Excavator Mounts
  • Skid Steer Mounts
  • Linkages
  • Adaptors
  • Torque Monitor Systems
  • Pressure Differential Gauges

Coming Soon

Features

High-Efficiency Hydraulic Motors: Equipped with Eaton/Digga bell geroler hydraulic motors featuring integrated pressure relief valves, you will get higher RPM and greater torque than competing drives.

Energy Control Valve: Say goodbye to rapid oil decompression caused by pile kick-back. Our drives come standard with an Energy Control Valve (ECV / Swoosh Valve) ensuring smooth operation and extended equipment lifespan.

Robust Construction: Engineered with a sturdy hood and ears for maximum strength, our drives are built to withstand the toughest working conditions, providing you with unmatched durability and peace of mind.

Warranty Assurance: Backed by a 3-year gearbox and 2-year motor warranty, our drives offer not only superior performance but also long-term reliability.

Product Specifications

Rev-Pile Inc. 30,000 FT-LBS Screw Pile Drive Specifications

30ADS - 3500 PSI

Nominal Torque - 30,771 FT-LBS

Max Pressure - 3500 PSI @ 33 GPM

Max Flow - 61GPM @ 1800 PSI

Pressure Relief Valve - Included

Energy Control Valve - Included

Output Shaft - 100mm Square

Weight - 637 LBS (with hood)

Overall Length - 45.3” (with hood)

Overall Diameter - 14”

Optional Extras
  • HALO Alignment System (Magnetic Battery Pack or Power Cables Sold Separately)
  • Excavator Mounts
  • Skid Steer Mounts
  • Linkages
  • Adaptors
  • Torque Monitor Systems
  • Pressure Differential Gauges
