HH-6K Handheld

• Compact high torque Digga manufactured gearbox
• Lightweight and compact for ease of movement in confined spaces
• Fitted with a high efficiency Danfoss/Digga geroler hydraulic motor
• Motor mounted pressure relief valve fitted standard
• 1yr gearbox and 1yr motor warranty

MODEL HH-6K
Theoretical Torque (ft-lbs) 6,528 @ 2,100psi
Expected Torque (ft-lbs) 4,765 @ 2,100psi
(73% efficiency)
Max Pressure 2,100psi @ 15gpm
Max Flow 15gpm @ 2100psi
Max Horse Power 18
Pressure Relief Valve Included
Standard Output Shaft 2” Hex
Weight (lbs) 90
Overall Length (in) 20”
Diameter (in) 9.5”

HH-6K unit is not suitable for machine mounting. Warranty void if used on machines.
